Product description

Specifications:

X Axis Travel: 30″
Y Axis Travel: 16″
Z Axis Travel: 20″
Rapid Rate X Axis: 1,400 IPM
Rapid Rate Y Axis: 1,400 IPM
Rapid Rate Z Axis: 1,400 IPM
Max Table Load: 1,500 LBS

Spindle Speed: 10,000 RPM
Spindle Taper: 40 CT
Tool Changer: 30 ATC
Max Cutting: 833 ipm
Max Weight: 1500 lb
Max Thrust X: 1995 lbf
Max Thrust Y: 1995 lbf
Max Thrust Z: 3085 lbf
Chip-to-Chip: 3.6 s
Coolant Cap: 55 gal
Amps 3 Phase 35A (High)
Table Size: 36″ x 14″
Weight: 7,800 LBS

Options:

HAAS CNC Control
Programmable Coolant
Pre-wired for 4th Axis
